AMD Ryzen™ 7 5800XT

• General Specifications

  NameAMD Ryzen™ 7 5800XT

  FamilyRyzen

  SeriesRyzen 5000 Series

  Form FactorBoxed Processor , Desktops

  Market SegmentEnthusiast Desktop

  Regional AvailabilityGlobal

  Former CodenameVermeer

  ArchitectureZen 3

  # of CPU Cores8

  Multithreading (SMT)Yes

  # of Threads16

  Max. Boost Clock Up to 4.8 GHz

  Base Clock 3.8 GHz

  L1 Cache512 KB

  L2 Cache4 MB

  L3 Cache32 MB

  Default TDP105W

  Processor Technology for CPU CoresTSMC 7nm FinFET

  Processor Technology for I/O Die12nm (Globalfoundries)

  CPU Compute Die (CCD) Size74mm²

  I/O Die (IOD) Size125mm²

  Package Die Count2

  Unlocked for Overclocking Yes

  CPU SocketAM4

  Supporting ChipsetsX570 , B550 , A520 , X470 , B450

  CPU Boost TechnologyPrecision Boost 2

  Instruction Setx86-64

  Supported ExtensionsAES , AMD-V , AVX , AVX2 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

  Thermal Solution (PIB)AMD Wraith Prism

  Max. Operating Temperature (Tjmax)90°C

  Launch Date07/31/2024

  *OS SupportWindows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

• Connectivity

  Native USB 3.2 Gen 2 (10Gbps)4

  Native USB 3.2 Gen 1 (5Gbps)0

  Native USB 2.0 (480Mbps)0

  Native SATA Ports2

  PCI Express® VersionPCIe® 4.0

  Native PCIe® Lanes (Total/Usable)24 , 20

  Additional Usable PCIe Lanes from Motherboard

  amd_x570

  16x Gen 4

  amd_x470

  2x Gen 3, 8x Gen 2

  NVMe SupportBoot , RAID0 , RAID1 , RAID10

  System Memory TypeDDR4

  Memory Channels2

  Max. Memory128 GB

  System Memory SubtypeUDIMM

  Max Memory Speed

  2x1R

  DDR4-3200

  2x2R

  DDR4-3200

  4x1R

  DDR4-2933

  4x2R

  DDR4-2667

  ECC SupportYes (Requires mobo support)

• Graphics Capabilities

  Graphics ModelDiscrete Graphics Card Required

• Product IDs

  Product ID Boxed100-100001582BOX , 100-100001582CBX

  Product ID Tray100-000001582

  Product ID MPK100-100001582MPK , 100-100001582CPK

• Key Features

  Supported TechnologiesAMD Zen 3 Core Architecture , AMD StoreMI Technology , AMD Ryzen™ Master Utility , AMD Ryzen™ VR-Ready Premium
