Interface
-
PCI Express 4.0×4, NVMe 1.4
-
Form Factor
-
M.2 2280
-
Total Capacity
-
1000GB
-
External DDR Cache
-
N/A
-
Sequential Read speed
-
Up to 4,000 MB/s
-
Sequential Write speed
-
Up to 3,900MB/s
-
Dimension
-
80 x 22 x 2.3 mm
-
Mean time between failure (MTBF)
-
1.5 million hours
-
Max. Operating Power
-
Read: 4400mW
Write: 4000mW
-
Power Consumption (Idle, PS3)
-
35mW
-
Power Consumption(PS4, L1.2)
-
5mW
-
Temperature (Operating)
-
0°C to 70°C
-
Temperature (Storage)
-
-40°C to 85°C
-
Warranty
-
1. Limited 3-years or 320TBW.
2. Limited warranty based on 3 years or 320TBW, whichever comes first. (*TBW is evaluated by JEDEC workload standard. )
*TBW (Terabyte Written): Terabytes Written is the total amount of data that can be written into a SSD before it is likely to fail.3. When the usage of an NVME SSD as indicated by the “Percentage Used” (SMART ID: 05) in SMART page of “GIGABYTE SSD toolbox” reaches 100 means out of warranty. (A new unused product will show the number of 0)
