B4-mATX
- Compact 21.3L mATX case with broad compatibility.
- Supports M-ATX / Mini-ITX, 358mm 4-slot GPUs, and 140mm ATX PSUs.
- Supports up to 360mm radiators with SFX PSU, or 240mm with ATX PSU.
- Up to 165mm CPU cooler clearance, or 159mm with side fan bracket.
- Includes 2 pre-installed 120 × 120 × 15mm slim top fans.
- Supports up to 9 fans across top, side, bottom, rear, and front.
- Removable top bracket simplifies CPU 8-pin routing and fan setup.
- Removable front bracket allows easier large GPU installation.
- Supports both horizontal and vertical layouts.
- Optional Vertical AeroDeck adds up to 3 × 120mm or 2 × 140mm fans for GPU cooling.
3,899 EGP
Out of stock
Out of stock
14
People watching this product now!
Description
SPECIFICATIONS
| PRODUCT NAME | B4-mATX Mesh | B4-mATX Wood | B4-mATX Vertical AeroDeck |
|---|---|---|---|
| MODEL NO. | B4X/B4W | B4X-WD/B4W-WD | B4-1X/B4-1W |
| COLOR | Black / White | Black / White | Black / White |
| DIMENSIONS (DxWxH) | 420 x 191 x 288mm | 420 x 191 x 288mm | 407x 191 x41.2mm |
| MATERIAL | Steel | Steel, Wood (Walnut / Beech) |
Tempered Glass, Steel Wood (Walnut / Beech) |
| MOTHERBOARD SUPPORT |
Back-Connect: NO / Micro-ATX, Mini ITX | ||
| STORAGE | Front: 2.5” SSD x 1 Bottom: 3.5” HDD x 1 or 2.5” SSD x 1 |
||
| GPU LENGTH CLEARANCE | 358mm | ||
| CPU COOLER HEIGHT CLEARANCE |
159mm (165mm without side fan bracket) | ||
| PSU SUPPORT | ATX (Up to 140mm) / SFX | ||
| RADIATOR SUPPORT | Side (With SFX PSU) 360mm / 280mm /240mm Side (With ATX PSU): 240mm |
||
| FAN SUPPORT | Top: 120mm x 2 (Pre-installed) Side (With SFX PSU) 120mm x 3 / 140mm x 2 Side (With ATX PSU): 120mm x 2 Front (With SFX PSU ONLY): 120mm slim fan x 1 Bottom: 120 mm x 3 / 140mm x 2 Rear: 120 mm x 1 |
Top:120mm x 1 Side(With SFX PSU):120mm x 3 / 140mm x 2 Side(With ATX PSU):120mm x 2 Front:120mm x 3 Bottom:120mm x 1 |
|
| INCLUDED FANS | Top: 120x120x15mm (x2) | ||
| DUST FILTER | Bottom: Magnetic Filter x 1 | PVC Dust Filter x 1 | |
| I/O PORTS | USB 3.0 Type A x 2 Power Button x 1 Audio x 1 USB 3.2 Type C x 1 |
||
