Lian Li RS1000G black 80+Gold
- 80 Plus Gold certified with Cybenetics Platinum-level efficiency performance.
- 90° rotatable AC inlet for standard or vertical PSU installation
- German EPCOS industrial-grade capacitors for long-term reliability
- Compact 150 × 86 × 150 mm ATX design with 135 mm cooling fan
- Ultra-quiet operation with PPLP.info SSS and Cybenetics A noise ratings
- ATX 3.1 ready with native 12V-2×6 high-current copper alloy terminals
- Dual-sided 20+4-pin ATX output for easier 24-pin cable routing
Category: Power supplyTags: 12V-2×6 Connector, 135 mm Fan, 150 mm Length, 20+4 Pin, 80 PLUS Gold, ATX 3.1, cable management, Compact ATX PSU, Cybenetics A Noise, Cybenetics Platinum, Dual-Sided 24-Pin, High Efficiency, High-Current Terminals, PPLP.info Gold, PPLP.info SSS, Quiet Cooling, Rotatable AC Inlet, Rotational Shift, RS Hub, RS Series
7,199 EGP
12
People watching this product now!
Description
SPECIFICATIONS
| PRODUCT NAME | RS1200G | RS1000G | |
|---|---|---|---|
| MODEL NO. | RS1200G | RS1000G | |
| Color | Black: RS1200G.BH00
White: RS1200G.WH00 |
Black: RS1000G. BH00
White: RS1000G. WH00 |
Black: RS1000G .B000
White: RS1000G .W000 |
| With Hub | Yes | Yes | No |
| ATX12V VERSION | ATX 3.1 | ||
| EFFICIENCY | 80 PLUS Gold / Cybenetics Platinum / PPLP Gold | ||
| DC OUTPUT CABLE | Full-Modular | ||
| DIMENSIONS | (D)150 mm X (W)86 mm X (H)150 mm | ||
| MATERIAL | SECC | ||
| PFC | Active PFC, PF > 0.90 under full load @ 115Vac, 60Hz | ||
| INPUT RATING | 100-240Vac 15-8A, 50-60Hz |
||
| MAX. DC OUTPUT | 1200W | 1000W | |
| COMBINED +12V | 1200W | 1000W | |
| COMBINED +3.3V & +5V | 100W | ||
| FAN SPEC | 135mm FDB Fan | ||
| FAN RPM | 2400rpm | 1600rpm | |
| FANLESS MODE | YES | ||
| NOISE LEVEL | 36.27dBA @ 30℃, 100cm away from micphone to PSU | 36.21dBA @ 30℃, 100cm away from micphone to PSU | |
| MTBF | 100,000 hrs minimum 25℃/75% Load | ||
| PROTECTION | OCP,OVP,OTP,OPP,SCP,UVP,NLP,SIP | ||
| WORKING TEMPERATURE | 0-40℃ | ||
| WARRANTY | 10 Years | ||
