Radeon™ RX 9070 XT GAMING OC 16G

Graphics Processing

Radeon™ RX 9070 XT
Core Clock

Boost Clock* : up to 3060 MHz (Reference card: 2970 MHz)
Game Clock* : up to 2520 MHz (Reference card: 2400 MHz)
Stream Processors

4096
Memory Clock

20 Gbps
Memory Size

16GB
Memory Type

GDDR6
Memory Bus

256 bit
Card Bus

PCI-E 5.0
Digital max resolution

7680×4320
Multi-view

4
Card size

L=288 W=132 H=56 mm
PCB Form

ATX
DirectX

DirectX 12 API
OpenGL

4.6
Recommended PSU

850W
Power Connectors

8 pin*3
Output

DisplayPort 2.1a *2
HDMI 2.1b *2
Accessories

Quick guide
Note

* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. GD-151
* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. GD-147
